Chapter 46 Protocol-based VLAN Commands
Ethernet Switch CLI Reference Guide
156
46.3 Command Examples
This example creates an IP based VLAN called IP_VLAN on ports 1-4 with a VLAN ID of
200 and a priority 6.
protocol-based-vlan name
<name> ethernet-type <ether-
num|ip|ipx|arp|rarp|appleta
lk|decnet> vlan <vlan-id>
priority <0-7>
Creates a protocol based VLAN with the specified
parameters.
name - Use up to 32 alphanumeric characters.
ether-num - if you don’t select a predefined Ethernet
protocol (ip, ipx, arp, rarp, appletalk or decnet), type
the protocol number in hexadecimal notation. For example,
the IP protocol in hexadecimal notation is 0800 and Novell
IPX is 8137.
Note: Protocols in the hexadecimal number range
0x0000 to 0x05ff are not allowed.
priority - specify the IEEE 802.1p priority that the Switch
assigns to frames belonging to this VLAN.
C13
no protocol-based-vlan
ethernet-type <ether-
num|ip|ipx|arp|rarp|appleta
lk|decnet>
Disables protocol based VLAN of the specified protocol on
the port.
C13
Table 99 protocol-based-vlan Command Summary (continued)
COMMAND DESCRIPTION M P
sysname(config)# interface port-channel 1-4
sysname(config-interface)# protocol-based-vlan name IP_VLAN ethernet-type ip
--> vlan 200 priority 6
sysname(config-interface)# exit
sysname(config)# exit
sysname# show interfaces config 1-4 protocol-based-vlan
Name Port Packet type Ethernet type Vlan Priority Active
------- ---- ----------- ------------- ---- -------- ------
IP_VLAN 1 EtherII ip 200 6 Yes
IP_VLAN 2 EtherII ip 200 6 Yes
IP_VLAN 3 EtherII ip 200 6 Yes
IP_VLAN 4 EtherII ip 200 6 Yes
sysname#
