![Zyxel ES-3124 [193/250] Trunk commands](/views2/1168512/page193/bgc1.png)
Ethernet Switch CLI Reference Guide
193
CHAPTER 60
Trunk Commands
Use these commands to logically aggregate physical links to form one logical, higher-
bandwidth link. The Switch adheres to the IEEE 802.3ad standard for static and dynamic
(Link Aggregate Control Protocol, LACP) port trunking.
" Different models support different numbers of trunks (T1, T2, ...). This chapter
uses a model that supports three trunks (T1, T2, and T3).
60.1 Command Summary
The following section lists the commands for this feature.
Table 127 trunk Command Summary
COMMAND DESCRIPTION M P
show trunk Displays link aggregation information. E 3
trunk <T1|T2|T3> Activates a trunk group. C 13
no trunk <T1|T2|T3> Disables the specified trunk group. C 13
trunk <T1|T2|T3> interface
<port-list>
Adds a port(s) to the specified trunk group. C 13
no trunk <T1|T2|T3> interface
<port-list>
Removes ports from the specified trunk group. C 13
trunk <T1|T2|T3> lacp Enables LACP for a trunk group. C 13
no trunk <T1|T2|T3> lacp Disables LACP in the specified trunk group. C 13
trunk interface <port-list>
timeout <lacp-timeout>
Defines LACP timeout period (in seconds) for the specified
port(s).
lacp-timeout: 1 or 30
C13
Table 128 lacp Command Summary
COMMAND DESCRIPTION M P
show lacp Displays LACP (Link Aggregation Control Protocol) settings. E 3
lacp Enables Link Aggregation Control Protocol (LACP). C 13
no lacp Disables the link aggregation control protocol (dynamic
trunking) on the Switch.
C13
lacp system-priority <1-65535> Sets the priority of an active port using LACP. C 13
