Chapter 68 Additional Commands
Ethernet Switch CLI Reference Guide
218
This example shows the current status of the various alarms in the Switch.
The following table describes the labels in this screen.
This example shows the current and recent CPU utilization.
The following table describes the labels in this screen.
sysname# show alarm-status
name status suppressAlarm alarmLED
----------------- ------ ------------- --------
VOLTAGE Normal No Off
TEMPERATURE Normal No Off
FAN Normal No Off
POE OVER LOAD Normal No Off
POE SHORT CIRCUIT Normal No Off
POE POWERBOX Normal Yes Off
Table 145 show alarm-status
LABEL DESCRIPTION
name This field displays the name or type of the alarm.
status This field displays the status of the alarm.
Normal: The alarm is off.
Error: The alarm is on.
suppressAlarm This field displays whether or not the alarm is inactive.
alarmLED This field displays whether or not the LED for this alarm is on.
sysname# show cpu-utilization
CPU usage status:
baseline 1715384 ticks
sec ticks util sec ticks util sec ticks util sec ticks
util
--- ------- ------ --- ------- ------ --- ------- ------ --- -------
0 657543 61.67 1 255118 85.13 2 394329 77.01 3 620008
63.85
4 195580 88.60 5 791000 53.89 6 137625 91.98 7 508456
70.36
--------------------------------- SNIP ---------------------------------
Table 146 show cpu-utilization
LABEL DESCRIPTION
baseline This field displays the number of CPU clock cycles per second.
sec This field displays the historical interval.
Interval 0 is the time starting one second ago to the current instant.
Interval 1 is the time starting two seconds ago to one second ago.
Interval 2 is the time starting three seconds ago to two seconds ago.
ticks This field displays the number of CPU clock cycles the CPU was not used
during the interval.
util This field displays the CPU utilization during the interval.
util = [(baseline - ticks) / baseline] * 100
