Chapter 42 PoE Commands
Ethernet Switch CLI Reference Guide
145
Allocated Power This field displays the total amount of power the Switch has reserved for
PoE after negotiating with the PoE device(s).
Remaining Power This field displays the amount of power the Switch can still provide for PoE.
Note: The Switch must have at least 16 W of remaining power
in order to supply power to a PoE device, even if the
PoE device requested less than 16 W.
Table 95 show pwr (continued)
LABEL DESCRIPTION
