![Zyxel ES-3124 [128/250] Command examples](/views2/1168512/page128/bg80.png)
Chapter 37 MSTP Commands
Ethernet Switch CLI Reference Guide
128
37.2 Command Examples
This example shows the current MSTP configuration.
The following table describes the labels in this screen.
no mstp instance <0-16> vlan <1-4094> Disables the assignment of specific VLANs from an
MST instance.
C13
mstp instance <0-16> interface port-
channel <port-list>
Specifies the ports you want to participate in this
MST instance.
C13
no mstp instance <0-16> interface port-
channel <port-list>
Disables the assignment of specific ports from an
MST instance.
C13
mstp instance <0-16> interface port-
channel <port-list> path-cost <1-
65535>
Specifies the cost of transmitting a frame to a LAN
through the port(s). It is recommended you assign it
according to the speed of the bridge.
C13
mstp instance <0-16> interface port-
channel <port-list> priority <1-255>
Sets the priority for the specified ports. Priority
decides which port should be disabled when more
than one port forms a loop in a Switch. Ports with a
higher priority numeric value are disabled first.
C13
Table 86 mstp instance Command Summary (continued)
COMMAND DESCRIPTION M P
sysname# show mstp
(a)BridgeMaxAge: 20 (seconds)
(b)BridgeHelloTime: 2 (seconds)
(c)BridgeForwardDelay: 15 (seconds)
(d)BridgeMaxHops: 128 (seconds)
(e)TransmissionLimit: 3
(f)ForceVersion: 3
(g)MST Configuration ID
Format Selector: 0
Configuration Name: 001349aefb7a
Reveision Number: 0
Configuration Digest: 0xAC36177F50283CD4B83821D8AB26DE62
msti vlans mapped
-----------------------------
0 1-4094
-----------------------------
Table 87 show mstp
LABEL DESCRIPTION
BridgeMaxAge This field displays the maximum time (in seconds) the Switch can wait
without receiving a configuration message before attempting to reconfigure.
BridgeHelloTime This field displays the time interval (in seconds) at which the Switch
transmits a configuration message.
BridgeForwardDelay This field displays the time (in seconds) the Switch will wait before
changing states (that is, listening to learning to forwarding).
BridgeMaxHops This field displays the number of hops (in seconds) in an MSTP region
before the BPDU is discarded and the port information is aged.
