Zyxel ES-3124 [17/250] Chapter 2 privilege level and command mode
![Zyxel ES-3124PWR [17/250] Chapter 2 privilege level and command mode](/views2/1168512/page17/bg11.png)
Chapter 2 Privilege Level and Command Mode
Ethernet Switch CLI Reference Guide
17
<password> consists of 1-32 alphanumeric characters. For example, the following
command sets the password for privilege level 13 to pswd13. See Chapter 68 on page 215 for
more information about this command.
2.1.3.3 disable Command
This command reduces the session’s privilege level to 0. It also changes the session to user
mode. This command is available in enable mode.
2.2 Command Modes
The CLI is divided into several modes. If a user has enough privilege to run a particular
command, the user has to run the command in the correct mode. The modes that are available
depend on the session’s privilege level.
2.2.1 Command Modes for Privilege Levels 0-12
If the session’s privilege level is 0-12, the user and all of the allowed commands are in user
mode. Users do not have to change modes to run any allowed commands.
2.2.2 Command Modes for Privilege Levels 13-14
If the session’s privilege level is 13-14, the allowed commands are in one of several modes.
sysname(config)# password pswd13 privilege 13
Table 7 Command Modes for Privilege Levels 13-14 and the Types of Commands in Each One
MODE PROMPT COMMAND FUNCTIONS IN THIS MODE
enable sysname# Display current configuration, diagnostics, maintenance.
config sysname(config)# Configure features other than those below.
config-interface sysname(config-interface)# Configure ports.
config-interface sysname(config-interface)# Configure ports.
config-mvr sysname(config-mvr)# Configure multicast VLAN.
config-route-
domain
sysname(config-if)# Enable and enter configuration mode for an IP routing
domain.
config-dvmrp sysname(config-dvmrp)# Configure Distance Vector Multicast Routing Protocol
(DVRMP).
config-igmp sysname(config-igmp)# Configure Internet Group Management Protocol (IGMP).
config-ospf sysname(config-ospf)# Configure Open Shortest Path First (OSPF) protocol.
config-rip sysname(config-rip)# Configure Routing Information Protocol (RIP).
config-vrrp sysname(config-vrrp)# Configure Virtual Router Redundancy Protocol (VRRP).
