Ethernet Switch CLI Reference Guide
169
CHAPTER 52
SNMP Server Commands
Use these commands to configure SNMP on the Switch.
52.1 Command Summary
The following table describes user-input values available in multiple commands for this
feature.
The following section lists the commands for this feature.
Table 110 snmp-server User-input Values
COMMAND DESCRIPTION
property 1-32 alphanumeric characters
options aaa: authentication, accounting.
interface: linkup, linkdown, autonegotiation.
ip: ping, traceroute.
switch: stp, mactable, rmon.
system: coldstart, warmstart, fanspeed, temperature, voltage,
reset, timesync, intrusionlock, loopguard.
Table 111 snmp-server Command Summary
COMMAND DESCRIPTION M P
show snmp-server Displays SNMP settings. E 3
snmp-server <[contact <system-
contact>] [location <system-
location>]>
Sets the geographic location and the name of the person in
charge of this Switch.
system-contact: 1-32 English keyboard characters;
spaces are allowed.
system-location: 1-32 English keyboard characters;
spaces are allowed.
C13
snmp-server version
<v2c|v3|v3v2c>
Sets the SNMP version to use for communication with the
SNMP manager.
C13
snmp-server get-community
<property>
Sets the get community. Only for SNMPv2c or lower. C 13
snmp-server set-community
<property>
Sets the set community. Only for SNMPv2c or lower. C 13
snmp-server trap-community
<property>
Sets the trap community. Only for SNMPv2c or lower. C 13
snmp-server trap-destination
<ip> [udp-port <socket-number>]
[version <v1|v2c|v3>] [username
<name>]
Sets the IP addresses of up to four SNMP managers (stations
to send your SNMP traps to). You can configure up to four
managers.
C13
