Chapter 62 VLAN Commands
Ethernet Switch CLI Reference Guide
200
" See Chapter 24 on page 97 for interface port-channel commands.
62.3 Command Summary
The following section lists the commands for this feature.
The following section lists the commands for the ingress checking feature
" VLAN ingress checking implementation differs across Switch models.
• Some models enable or disable VLAN ingress checking on all the ports via the vlan1q
ingress-check command.
Table 132 vlan Command Summary
COMMAND DESCRIPTION M P
show vlan Displays the status of all VLANs. E 3
show vlan <vlan-id> Displays the status of the specified VLAN. E 3
vlan-type <802.1q|port-based> Specifies the VLAN type. C 13
vlan <vlan-id> Enters config-vlan mode for the specified VLAN. Creates the
VLAN, if necessary.
C13
fixed <port-list> Specifies the port(s) to be a permanent member of this VLAN
group.
C13
no fixed <port-list> Sets fixed port(s) to normal port(s). C 13
forbidden <port-list> Specifies the port(s) you want to prohibit from joining this
VLAN group.
C13
no forbidden <port-list> Sets forbidden port(s) to normal port(s). C 13
inactive Disables the specified VLAN. C 13
no inactive Enables the specified VLAN. C 13
name <name> Specifies a name for identification purposes.
name: 1-64 English keyboard characters
C13
normal <port-list> Specifies the port(s) to dynamically join this VLAN group
using GVRP
C13
untagged <port-list> Specifies the port(s) you don’t want to tag all outgoing frames
transmitted with this VLAN Group ID.
C13
no untagged <port-list> Specifies the port(s) you want to tag all outgoing frames
transmitted with this VLAN Group ID.
C13
no vlan <vlan-id> Deletes a VLAN. C 13
