Chapter 35 Mirror Commands
Ethernet Switch CLI Reference Guide
124
35.2 Command Examples
This example enables port mirroring and copies outgoing traffic from ports 1, 4, 5, and 6 to
port 3.
Table 83 mirror-filter Command Summary
COMMAND DESCRIPTION M P
mirror-filter egress mac <mac-
addr>
Specifies the source or destination MAC address that the
Switch uses to decide whether or not to copy outgoing traffic
to mirrored ports to the monitor port.
C13
mirror-filter egress type
<all|dest|src>
all: Specifies that the Switch should copy all outgoing traffic
from mirrored ports.
dest: Specifies that the Switch should copy all outgoing
traffic from mirrored ports to the specified destination MAC
address.
src: Specifies that the Switch should copy all outgoing traffic
from mirrored ports from the specified source MAC address.
C13
mirror-filter ingress mac <mac-
addr>
Specifies the source or destination MAC address that the
Switch uses to decide whether or not to copy incoming traffic
from mirrored ports to the monitor port.
C13
mirror-filter ingress type
<all|dest|src>
all: Specifies that the Switch should copy all incoming traffic
from mirrored ports.
dest: Specifies that the Switch should copy all incoming
traffic from mirrored ports to the specified destination MAC
address.
src: Specifies that the Switch should copy all incoming traffic
from mirrored ports from the specified source MAC address.
C13
sysname(config)# mirror-port
sysname(config)# mirror-port 3
sysname(config)# interface port-channel 1,4-6
sysname(config-interface)# mirror
sysname(config-interface)# mirror dir egress
