Ethernet Switch CLI Reference Guide
207
CHAPTER 65
VLAN Stacking Commands
Use these commands to add an outer VLAN tag to the inner IEEE 802.1Q tagged frames that
enter your network.
65.1 Command Summary
The following section lists the commands for this feature.
65.2 Command Examples
In the following example figure, both A and B are Service Provider’s Network (SPN)
Table 138 vlan-trunking Command Summary
COMMAND DESCRIPTION M P
show vlan-stacking Displays VLAN stacking settings. E 3
vlan-stacking Enables VLAN stacking on the Switch. C 13
no vlan-stacking Disables VLAN stacking on the Switch. C 13
vlan-stacking <sptpid> Sets the SP TPID (Service Provider Tag Protocol Identifier).
SP TPID is a standard Ethernet type code identifying the
frame and indicating whether the frame carries IEEE 802.1Q
tag information. Enter a four-digit hexadecimal number from
0000 to FFFF.
C13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
vlan-stacking priority <0-7> Sets the priority of the specified port(s) in VLAN stacking. C 13
vlan-stacking role
<normal|access|tunnel>
Sets the VLAN stacking port roles of the specified port(s).
normal: The Switch ignores frames received (or transmitted)
on this port with VLAN stacking tags.
access: the Switch adds the SP TPID tag to all incoming
frames received on this port.
tunnel: (available for Gigabit and faster ports only) for
egress ports at the edge of the service provider's network.
Note: In order to support VLAN stacking on a port,
the port must be able to allow frames of
1526 Bytes (1522 Bytes + 4 Bytes for the
second tag) to pass through it.
C13
vlan-stacking SPVID <1-4094> Sets the service provider VID of the specified port(s). C 13
