Zyxel ES-3124 [217/250] Command examples
![Zyxel ES-3124 [217/250] Command examples](/views2/1168512/page217/bgd9.png)
Chapter 68 Additional Commands
Ethernet Switch CLI Reference Guide
217
68.2 Command Examples
This example checks the cable pairs on port 7.
This example sends Ping requests to an Ethernet device with IP address 172.16.37.254.
The following table describes the labels in this screen.
sysname# cable-diagnostics 7
port 7
cable diagnostics result
pairA: Ok
pairB: Ok
sysname# ping 172.16.37.254
Resolving 172.16.37.254... 172.16.37.254
sent rcvd rate rtt avg mdev max min reply from
1 1 100 0 0 0 0 0 172.16.37.254
2 2 100 0 0 0 0 0 172.16.37.254
3 3 100 10 1 3 10 0 172.16.37.254
Table 144 ping
LABEL DESCRIPTION
sent This field displays the sequence number of the ICMP request the Switch
sent.
rcvd This field displays the sequence number of the ICMP response the Switch
received.
rate This field displays the percentage of ICMP responses for ICMP requests.
rtt This field displays the round trip time of the ping.
avg This field displays the average round trip time to ping the specified IP
address.
mdev This field displays the standard deviation in the round trip time to ping the
specified IP address.
max This field displays the maximum round trip time to ping the specified IP
address.
min This field displays the minimum round trip time to ping the specified IP
address.
reply from This field displays the IP address from which the Switch received the ICMP
response.
