Chapter 31 MAC Address Commands
Ethernet Switch CLI Reference Guide
116
31.2 Command Examples
This example shows the current MAC address table.
The following table describes the labels in this screen.
sysname# show mac address-table all
Port VLAN ID MAC Address Type
2 1 00:00:e8:7c:14:80 Dynamic
2 1 00:04:80:9b:78:00 Dynamic
2 1 00:0f:fe:ad:58:ab Dynamic
2 1 00:13:49:6b:10:55 Dynamic
2 1 00:13:d3:f0:7e:f0 Dynamic
2 1 00:18:f8:04:f5:67 Dynamic
2 1 00:80:c8:ef:81:d3 Dynamic
2 1 00:a0:c5:00:00:01 Dynamic
Table 77 show mac address-table
LABEL DESCRIPTION
Port This is the port from which the above MAC address was learned.
Drop: The entry is created from a filtering rule.
VLAN ID This is the VLAN group to which this frame belongs.
MAC Address This is the MAC address of the device from which this frame came.
Type This shows whether the MAC address is dynamic (learned by the Switch)
or static (manually entered using mac-forward commands, see Chapter
34 on page 121).
