Chapter 22 IGMP Snooping Commands
Ethernet Switch CLI Reference Guide
93
22.2 Command Examples
This example enables IGMP snooping on the Switch, sets the host-timeout and leave-
timeout
values to 30 seconds, and sets the Switch to drop packets from unknown multicast
groups.
This example limits the number of multicast groups on port 1 to 5.
This example shows the current multicast groups on the Switch.
no igmp-immediate-leave Disables the immediate leave function for IGMP snooping. C 13
igmp-querier-mode
<auto|fixed|edge>
Specifies whether or not and under what conditions the
port(s) is (are) IGMP query port(s). The Switch forwards
IGMP join or leave packets to an IGMP query port, treating
the port as being connected to an IGMP multicast router (or
server). You must enable IGMP snooping as well.
fixed: The Switch always treats the port(s) as IGMP query
port(s). Select this when you connect an IGMP multicast
server to the port(s).
auto: The Switch uses the port as an IGMP query port if the
port receives IGMP query packets.
edge: The Switch does not use the port as an IGMP query
port. The Switch does not keep any record of an IGMP router
being connected to this port. The Switch does not forward
IGMP join or leave packets to this port.
C13
Table 60 interface igmp Command Summary (continued)
COMMAND DESCRIPTION M P
sysname(config)# igmp-snooping
sysname(config)# igmp-snooping host-timeout 30
sysname(config)# igmp-snooping leave-timeout 30
sysname(config)# igmp-snooping unknown-multicast-frame drop
sysname# configure
sysname(config)# igmp-snooping
sysname(config)# interface port-channel 1
sysname(config-interface)# igmp-group-limited
sysname(config-interface)# igmp-group-limited number 5
sysname(config-interface)# exit
sysname(config)# exit
sysname# show interfaces config 1 igmp-group-limited
Port Enable Max Multicast Group
1 YES 5
sysname# show multicast
Multicast Status
Index VID Port Multicast Group Timeout
----- ---- ---- ---------------- -------
