Chapter 24 Interface Commands
Ethernet Switch CLI Reference Guide
99
Link This field displays the speed (either 10M for 10 Mbps, 100M for 100 Mbps
or 1000M for 1000 Mbps) and the duplex (F for full duplex or H for half
duplex). It also shows the cable type (Copper or Fiber). This field displays
Down if the port is not connected to any device.
Status If STP (Spanning Tree Protocol) is enabled, this field displays the STP
state of the port. If STP is disabled, this field displays FORWARDING if the
link is up, otherwise, it displays STOP.
LACP This field shows if LACP is enabled on this port or not.
TxPkts This field shows the number of transmitted frames on this port
RxPkts This field shows the number of received frames on this port
Errors This field shows the number of received errors on this port.
Tx KBs/s This field shows the number kilobytes per second transmitted on this port.
Rx KBs/s This field shows the number of kilobytes per second received on this port.
Up Time This field shows the total amount of time the connection has been up.
Tx Packet
The following fields display detailed information about packets transmitted.
TX Packets This field shows the number of good packets (unicast, multicast and
broadcast) transmitted.
Multicast This field shows the number of good multicast packets transmitted.
Broadcast This field shows the number of good broadcast packets transmitted.
Pause This field shows the number of 802.3x Pause packets transmitted.
Rx Packet
The following fields display detailed information about packets received.
RX Packets This field shows the number of good packets (unicast, multicast and
broadcast) received.
Multicast This field shows the number of good multicast packets received.
Broadcast This field shows the number of good broadcast packets received.
Pause This field shows the number of 802.3x Pause packets received.
TX Collision
The following fields display information on collisions while transmitting.
Single This is a count of successfully transmitted packets for which transmission is
inhibited by exactly one collision.
Multiple This is a count of successfully transmitted packets for which transmission
was inhibited by more than one collision.
Excessive This is a count of packets for which transmission failed due to excessive
collisions. Excessive collision is defined as the number of maximum
collisions before the retransmission count is reset.
Late This is the number of times a late collision is detected, that is, after 512 bits
of the packets have already been transmitted.
Error Packet The following fields display detailed information about packets received that
were in error.
RX CRC This field shows the number of packets received with CRC (Cyclic
Redundant Check) error(s).
Runt This field shows the number of packets received that were too short
(shorter than 64 octets), including the ones with CRC errors.
Table 64 show interfaces (continued)
LABEL DESCRIPTION
