Ethernet Switch CLI Reference Guide
191
CHAPTER 59
TFTP Commands
Use these commands to back up and restore configuration and firmware via TFTP.
59.1 Command Summary
The following section lists the commands for this feature.
Table 126 tftp Command Summary
COMMAND DESCRIPTION M P
copy tftp flash <ip> <remote-
file>
Restores firmware via TFTP. E 13
copy tftp config <index> <ip>
<remote-file>
Restores configuration with the specified filename from the
specified TFTP server.
index: 1.
E13
copy running-config tftp <ip>
<remote-file>
Backs up running configuration to the specified TFTP server
with the specified file name.
E13
