Chapter 60 Trunk Commands
Ethernet Switch CLI Reference Guide
195
This example shows the current LACP settings.
The following table describes the labels in this screen.
sysname# show lacp
AGGREGATOR INFO:
ID: 1
[(0000,00-00-00-00-00-00,0000,00,0000)][(0000,00-00-00-00-00-00
-->,0000,00,0000)]
LINKS :
SYNCS :
ID: 2
[(0000,00-00-00-00-00-00,0000,00,0000)][(0000,00-00-00-00-00-00
-->,0000,00,0000)]
LINKS :
SYNCS :
ID: 3
[(0000,00-00-00-00-00-00,0000,00,0000)][(0000,00-00-00-00-00-00
--> ,0000,00,0000)]
LINKS :
SYNCS :
Table 130 show lacp
LABEL DESCRIPTION
ID This field displays the trunk ID to identify a trunk group, that is, one logical
link containing multiple ports.
[(0000,00-00-00-00-00-
00,0000,00,0000)]
This field displays the system priority, MAC address, key, port priority, and
port number.
LINKS This field displays the ports whose link state are up.
SYNCS These are the ports that are currently transmitting data as one logical link in
this trunk group.
