Chapter 42 PoE Commands
Ethernet Switch CLI Reference Guide
144
This example shows the current status and configuration of Power over Ethernet.
The following table describes the labels in this screen.
sysname# show pwr
Averaged Junction Temperature: 35 (c), 95 (f).
Port State PD Class Priority Consumption (mW) MaxPower(mW)
---- ------- --- ----- -------- ---------------- ------------
1 Disable off 0 Critical 0 0
2 Enable off 0 Critical 0 0
3 Enable off 0 Critical 0 0
4 Enable off 0 Critical 0 0
5 Enable off 0 Critical 0 0
6 Enable off 0 Critical 0 0
7 Enable off 0 Critical 0 0
--------------------------------- SNIP ---------------------------------
Total Power:185.0(W)
Consuming Power:0.0(W)
Allocated Power:0.0(W)
Remaining Power:185.0(W)
Table 95 show pwr
LABEL DESCRIPTION
Averaged Junction
Temperature
This field displays the internal temperature of the PoE chipset.
Port This field displays the port number.
State This field indicates whether or not PoE is enabled on this port.
PD This field indicates whether or not a powered device (PD) is allowed to
receive power from the Switch on this port.
Class This field displays the maximum power level at the input of the PoE-
enabled devices connected to this port. The range of the maximum power
used by the PD is described below.
0: 0.44~12.95 W
1: 0.44~3.84 W
2: 3.84~6.49 W
3: 6.49~12.95 W
Priority When the total power requested by the PDs exceeds the total PoE power
budget on the Switch, the Switch uses the PD priority to provide power to
ports with higher priority.
Consumption (mW) This field displays the amount of power the Switch is currently supplying to
the PoE-enabled devices connected to this port.
MaxPower(mW) This field displays the maximum amount of power the Switch can supply to
the PoE-enabled devices connected to this port.
Total Power This field displays the total power the Switch can provide to PoE-enabled
devices.
Consuming Power This field displays the amount of power the Switch is currently supplying to
the PoE-enabled devices.
