Chapter 2 Privilege Level and Command Mode
Ethernet Switch CLI Reference Guide
19
3 Copy and paste the results into a text editor of your choice. This creates a list of all the
executable commands in the user and enable modes.
4 Type configure and press [ENTER]. This takes you to the config mode.
5 Type help and press [ENTER]. A list is displayed which shows all the commands
available in config mode and all the sub-commands. The sub-commands are preceded by
the command necessary to enter that sub-command mode. For example, the command
name <name-str> as shown next, is preceded by the command used to enter the
config-vlan sub-mode:
vlan <1-4094>.
6 Copy and paste the results into a text editor of your choice. This creates a list of all the
executable commands in config and the other submodes, for example, the config-vlan
mode.
sysname# help
.
.
no arp inspection log-buffer logs
no arp inspection filter-aging-time
no arp inspection <cr>
vlan <1-4094>
vlan <1-4094> name <name-str>
vlan <1-4094> normal <port-list>
vlan <1-4094> fixed <port-list>
