Zyxel UAG5100 [100/361] Virtual interface specific commands
![Zyxel UAG5100 [100/361] Virtual interface specific commands](/views2/1169100/page100/bg64.png)
Chapter 13 Interfaces
UAG CLI Reference Guide
100
13.3.2.1 Port Grouping Command Examples
The following commands add physical port 5 to interface lan1.
The following commands set port 1 to use auto-negotiation auto and port 2 to use a 10 Mbps
connection speed and half duplex.
13.4 Virtual Interface Specific Commands
Virtual interfaces use many of the general interface commands discussed at the beginning of
Section 13.2 on page 86. There are no additional commands for virtual interfaces.
13.4.1 Virtual Interface Command Examples
The following commands set up a virtual interface on top of Ethernet interface lan1. The virtual
interface is named lan1:1 with the following parameters: IP 1.2.3.4, subnet 255.255.255.0,
Router# configure terminal
Router(config)# show port-grouping
No. Representative Name Port1 Port2 Port3 Port4 Port5
=========================================================
1 wan1 yes no no no no
2 wan2 no yes no no no
3 lan1 no no yes no no
4 lan2 no no no yes no
5 dmz no no no no yes
Router(config)# port-grouping lan1
Router(config-port-grouping)# port 5
Router(config-port-grouping)# exit
Router(config)# show port-grouping
No. Representative Name Port1 Port2 Port3 Port4 Port5
=========================================================
1 wan1 yes no no no no
2 wan2 no yes no no no
3 lan1 no no yes no yes
4 lan2 no no no yes no
5 dmz no no no no no
Router(config)# port status Port1
Router(config-port-status)# negotiation auto
Router(config-port-status)# exit
Router(config)# port status Port2
Router(config-port-status)# duplex half
Router(config-port-status)# speed 10
Router(config-port-status)# exit
Router(config)# exit
