Chapter 63 Packet Flow Explore
UAG CLI Reference Guide
319
The following example shows all activated dynamic VPN rules.
The following example shows all activated VPN 1-1 mapping rules.
The following example shows all activated static-dynamic VPN rules.
The following example shows all activated policy routes which use SNAT.
The following example shows all activated 1-to-1 NAT rules.
The following example shows all activated policy routes which use SNAT and enable NAT loopback..
Router> show system route dynamic-vpn
No. Source Destination VPN Tunnel
===========================================================================
Router> sshow system route vpn-1-1-map
No. Source Destination Outgoing Gateway
===========================================================================
Router> show ip route static-dynamic
Flags: A - Activated route, S - Static route, C - directly Connected
O - OSPF derived, R - RIP derived, G - selected Gateway
! - reject, B - Black hole, L - Loop
IP Address/Netmask Gateway IFace Metric Flags Persis
t
===========================================================================
0.0.0.0/0 10.1.1.254 wan1 0 ASG -
Router> show system snat policy-route
No. PR NO. Outgoing SNAT
===========================================================================
Router> show system snat nat-1-1
No. VS Name Source Destination Outgoing SNAT
===========================================================================
Router> show system snat nat-loopback
Note: Loopback SNAT will be only applied only when the initiator is located at the
network which the server locates at
No. VS Name Source Destination SNAT
===========================================================================
