Chapter 58 File Manager
UAG CLI Reference Guide
296
58.5 File Manager Command Examples
This example saves a back up of the current configuration before applying a shell script file.
These commands run the aaa.zysh script at noon every day, on the first day of every month, and
on every Monday, Wednesday, and Friday.
58.6 FTP File Transfer
You can use FTP to transfer files to and from the UAG for advanced maintenance and support.
58.6.1 Command Line FTP File Upload
1 Connect to the UAG.
2 Enter “bin” to set the transfer mode to binary.
3 You can upload the firmware after you log in through FTP. To upload other files, use “cd” to change
to the corresponding directory.
show running-config Displays the settings of the configuration file that the system is using.
[no] backup-startup activate Sets the UAG to back up the startup-conf.conf file when it is performing
firmware upgrade.
The no command disables the backup function.
show backup-startup status Displays whether the startup configuration backup function is enabled or
not.
setenv-startup stop-on-error off Has the UAG ignore any errors in the startup-config.conf file and apply all
of the valid commands.
show setenv-startup Displays whether or not the UAG is set to ignore any errors in the startup-
config.conf file and apply all of the valid commands.
write Saves your configuration changes to the flash (“non-volatile” or “long
term”) memory. The UAG immediately uses configuration changes made
via commands, but if you do not use the
write command, the changes
will be lost when the UAG restarts.
Table 190 File Manager Commands Summary (continued)
COMMAND DESCRIPTION
Router(config)# copy running-config /conf/backup.conf
Router(config)# run /script/vpn_setup.zysh
Router> configure terminal
Router(config)# schedule-run 1 aaa.zysh daily 12:00
Router(config)# schedule-run 1 aaa.zysh monthly 12:00 01
Router(config)# schedule-run 1 aaa.zysh weekly 12:00 mon wed fri
Router(config)#
