Zyxel UAG5100 [37/361] User and privilege modes
![Zyxel UAG5100 [37/361] User and privilege modes](/views2/1169100/page37/bg25.png)
UAG CLI Reference Guide 37
CHAPTER 2
User and Privilege Modes
This chapter describes how to use these two modes.
2.1 User And Privilege Modes
This is the mode you are in when you first log into the CLI. (Do not confuse ‘user mode’ with types
of user accounts the UAG uses. See Chapter 44 on page 224 for more information about the user
types. ‘User’ type accounts can only run ‘exit’ in this mode. However, they may need to log into the
device in order to be authenticated for ‘user-aware’ policies, for example a firewall rule that a
particular user is exempt from or a VPN tunnel that only certain people may use.)
Type ‘enable’ to go to ‘privilege mode’. No password is required. All commands can be run from
here except those marked with an asterisk. Many of these commands are for trouble-shooting
purposes, for example the htm (hardware test module) and debug commands. Customer support
may ask you to run some of these commands and send the results if you need assistance
troubleshooting your device.
For admin logins, all commands are visible in ‘user mode’ but not all can be run there. The following
table displays which commands can be run in ‘user mode’. All commands can be run in ‘privilege
mode’.
The htm and psm commands are for ZyXEL’s internal manufacturing
process.
Table 4 User (U) and Privilege (P) Mode Commands
COMMAND MODE DESCRIPTION
apply P Applies a configuration file.
atse U/P Displays the seed code
clear U/P Clears system or debug logs or DHCP binding.
configure U/P Use ‘configure terminal’ to enter configuration mode.
copy P Copies configuration files.
debug (*) U/P For support personnel only! The device needs to have the debug flag enabled.
delete P Deletes configuration files.
details P Performs diagnostic commands.
diag P Provided for support personnel to collect internal system information. It is not recommended
that you use these.
diag-info P Has the UAG create a new diagnostic file.
dir P Lists files in a directory.
disable U/P Goes from privilege mode to user mode
enable U/P Goes from user mode to privilege mode
