Zyxel UAG5100 [269/361] Dynamic guest accounts
![Zyxel UAG5100 [269/361] Dynamic guest accounts](/views2/1169100/page269/bg10d.png)
UAG CLI Reference Guide 269
CHAPTER 55
Dynamic Guest Accounts
55.1 Dynamic Guest Accounts Overview
Dynamic guest accounts are guest accounts, but are created dynamically and stored in the UAG’s
local user database. A dynamic guest account has a dynamically-created user name and password.
A dynamic guest account user can access the UAG’s services only within a given period of time and
will become invalid after the expiration date/time.
There are three types of dynamic guest accounts depending on how they are created or
authenticated: billing-users, ua-users and trial-users.
billing-users are guest account created with the dynamic-guest generate command or the guest
manager account or an external printer and paid by cash or created and paid via the on-line
payment service.
ua-users are users that log in from the user agreement page.
trial-users are free guest accounts that are created with the dynamic-guest generate-freeuser
command or the Free Time function.
55.2 Dynamic-guest Commands
This table lists the dynamic-guest commands. You must use the configure terminal command
to enter the configuration mode before you can use these commands.
Table 169 dynamic-guest Commands
COMMAND DESCRIPTION
dynamic-guest freeuser user_name Creates a free dynamic guest account (trial-user) with the specified user
name and enters the dynamic-guest sub-command mode to set the
password and timeout settings. See Table 170 on page 270 for the sub-
commands.
dynamic-guest generate Sets the UAG to automatically create a dynamic guest account (billing-
user) and enters the dynamic-guest sub-command mode to set the
password and timeout settings. See Table 170 on page 270 for the sub-
commands.
dynamic-guest generate-freeuser Sets the UAG to automatically create a free dynamic guest account (trial-
user) and enters the dynamic-guest sub-command mode to set the
password and timeout settings. See Table 170 on page 270 for the sub-
commands.
