Zyxel UAG5100 [261/361] Ssl application command examples
![Zyxel UAG5100 [261/361] Ssl application command examples](/views2/1169100/page261/bg105.png)
Chapter 53 SSL Application
UAG CLI Reference Guide
261
53.1.2 SSL Application Command Examples
The following commands create and display a server-type SSL application object named example
for a link to the website at http://www.example.com.
server-type weblink url url Sets this to create a link to a web site you specified that you expect the SSL
VPN users to commonly use.
url: Enter the fully qualified domain name (FQDN) or IP address of the
application server. You must enter the “http://” or “https://” prefix. For
example, https://1.2.3.4. SSL VPN users are restricted to access only
web pages or files in this directory. For example, if you enter “\remote\” in
this field, emote users can only access web pages or files in the “remote”
directory.
If a link contains a file that is not within this domain, then SSL VPN users
cannot access it.
no server-type Remove the type of service configuration for this SSL application.
[no] webpage-encrypt Turn on web encrypt to prevent users from saving the web content.
Table 166 SSL Application Object Commands
COMMAND DESCRIPTION
Router(config)# sslvpn application example
Router(sslvpn application)# server-type weblink url http://www.example.com
Router(sslvpn application)# exit
Router(config)# show sslvpn application
SSL Application: example
Server Type: weblink
URL: http://www.example.com
Entry Point:
Encrypted URL: ~aHR0cDovL2luZm8v/
Web Page Encryption: yes
Reference: 0
Server Address:
Starting Port:
Ending Port:
Program Path:
Router(config)#
