Chapter 4 Status
UAG CLI Reference Guide
46
Here are examples of the commands that display the fan speed, MAC address, memory usage, RAM
size, and serial number.
Here is an example of the command that displays the listening ports.
Here is an example of the command that displays the open ports.
Router(config)# show fan-speed
FAN1(F00)(rpm): limit(hi)=8000, limit(lo)=1400, max=6115, min=6115, avg=6115
Router(config)# show mac
MAC address: 00:00:AA:80:05:58-00:00:AA:80:05:5C
Router(config)# show mem status
memory usage: 39%
Router(config)# show ram-size
ram size: 512MB
Router(config)# show serial-number
serial number: Z34131340 80-009-011001AA
Router(config)#
Router(config)# show socket listen
No. Proto Local_Address Foreign_Address State
===============================================================================
1 tcp 127.0.0.1:2601 0.0.0.0:0 LISTEN
2 tcp 127.0.0.1:2602 0.0.0.0:0 LISTEN
3 tcp 127.0.0.1:2604 0.0.0.0:0 LISTEN
4 tcp 127.0.0.1:10444 0.0.0.0:0 LISTEN
5 tcp 0.0.0.0:80 0.0.0.0:0 LISTEN
6 tcp 192.168.3.1:53 0.0.0.0:0 LISTEN
7 tcp 10.113.243.21:53 0.0.0.0:0 LISTEN
8 tcp 127.0.0.1:53 0.0.0.0:0 LISTEN
9 tcp 0.0.0.0:21 0.0.0.0:0 LISTEN
10 tcp 0.0.0.0:22 0.0.0.0:0 LISTEN
11 tcp 127.0.0.1:953 0.0.0.0:0 LISTEN
12 tcp 0.0.0.0:443 0.0.0.0:0 LISTEN
Router(config)#
Router(config)# show socket open
No. Proto Local_Address Foreign_Address State
===============================================================================
1 udp 0.0.0.0:520 0.0.0.0:0
2 udp 192.168.3.1:4500 0.0.0.0:0
3 udp 10.113.243.21:4500 0.0.0.0:0
4 udp 10.113.243.21:47384 10.113.243.111:514
5 udp 0.0.0.0:161 0.0.0.0:0
6 udp 192.168.3.1:53 0.0.0.0:0
7 udp 10.113.243.21:53 0.0.0.0:0
8 udp 127.0.0.1:53 0.0.0.0:0
9 udp 0.0.0.0:67 0.0.0.0:0
10 udp 0.0.0.0:56915 0.0.0.0:0
11 udp 10.113.243.21:50526 10.113.243.251:514
12 udp 192.168.3.1:500 0.0.0.0:0
13 udp 10.113.243.21:500 0.0.0.0:0
Router(config)#
