Zyxel UAG5100 [233/361] Application object group commands
![Zyxel UAG5100 [233/361] Application object group commands](/views2/1169100/page233/bge9.png)
Chapter 45 Application Object
UAG CLI Reference Guide
233
45.1.1.1 application-object Examples
These are some example usage commands.
45.1.2 Application Object Group Commands
This table lists the application object group commands.
Router(config)# show application-object
Name
Description Ref
Content
===============================================================================
tests
New Create 1
Facebook Game (access)
Router(config)# show application-object tests
Name: tests
Description: New Create
Category Application
Application ID
===============================================================================
Social Network Facebook Game (access)
402685702
Router(config)#
Table 146 object-group application Commands
COMMAND DESCRIPTION
show object-group application
object_group_name
Displays information on the named application object group.
object-group application object_group_name Creates an application object group. with the specified name. You
may use 1-31 alphanumeric characters, underscores(
_), or dashes (-
), but the first character cannot be a number. This value is case-
sensitive. The no command disables it.
[no] description description Write a description of the object group.
[no] application-object object_name Adds the named application object to the object group. The no
command removes it.
no object-group application
<object_group_name
Deletes the object group with the specified name.
object-group application rename
object_group_name1 object_group_name2
Renames the specified object group with a new name.
