Chapter 60 Reports and Reboot
UAG CLI Reference Guide
312
60.2.1 Email Daily Report Example
This example sets the following about sending a daily report e-mail:
• Disables the reporting.
• Specifies example-SMTP-mail-server.com as the address of the SMTP mail server.
• Sets the subject of the report e-mails to test.
• Stops the system name from being appended to the mail subject.
• Appends the date and time to the mail subject.
• Sets the sender as my-email@example.com.
• Sets example-administrator@example.com as the first account to which to send the mail.
• Has the UAG not use the second and third mail-to options.
• Sets my-email@example.com as the fourth mail-to option.
• Has the UAG not use the fifth mail-to option.
• Has the UAG provide username 12345 and password 12345 to the SMTP server for
authentication.
• Sets the UAG to send the report at 1:57 PM.
• Has the UAG not reset the counters after sending the report.
• Has the report include CPU, memory, port, and session usage along with traffic statistics.
send-now Sends the daily e-mail report immediately.
[no] smtp-tls activate Sets the UAG to use Transport Layer Security (TLS) to have
encrypted communications between the mail server and the
UAG.
The
no command disables TLS in communications between
the mail server and the UAG.
[no] smtp-tls authenticate-server Sets the UAG to authenticate the mail server in the TLS
handshake.
The
no command sets the UAG to not authenticate the mail
server in the TLS handshake.
reset-counter-now Discards all report data and starts all of the report statistics
data counters over at zero.
exit Leaves the sub-command mode.
Table 201 Email Daily Report Commands (continued)
COMMAND DESCRIPTION
