Chapter 13 Interfaces
UAG CLI Reference Guide
96
[no] ip ospf dead-interval <1..65535> Sets the number of seconds the UAG waits for “hello” messages from
peer routers before it assumes the peer router is not available and
deletes associated routing information. The
no command sets the
number of seconds to 40. See ip ospf hello-interval for more
information.
[no] ip ospf retransmit-interval
<1..65535>
Sets the number of seconds the UAG waits for an acknowledgment in
response to a link state advertisement before it re-sends the
advertisement.
Link state advertisements (LSA) are used to share the link state and
routing information between routers.
Table 42 interface Commands: OSPF Settings (continued)
COMMAND DESCRIPTION
