Zyxel UAG5100 [274/361] Host name commands
![Zyxel UAG5100 [274/361] Host name commands](/views2/1169100/page274/bg112.png)
Chapter 56 System
UAG CLI Reference Guide
274
56.3 Host Name Commands
The following table describes the commands available for the hostname and domain name. You
must use the
configure terminal command to enter the configuration mode before you can use
these commands.
56.4 Time and Date
For effective scheduling and logging, the UAG system time must be accurate. The UAG’s Real Time
Chip (RTC) keeps track of the time and date. There is also a software mechanism to set the time
manually or get the current time and date from an external server.
login-page window-color {color-rgb |
color-name | color-number}
Sets the color of the login page’s window border.
logo background-color {color-rgb |
color-name | color-number}
Sets the color of the logo banner across the top of the login screen and
access page.
show access-page settings Lists the current access page settings.
show login-page default-title Lists the factory default title for the login page.
show login-page settings Lists the current login page settings.
show logo settings Lists the current logo background (banner) and floor (line below the
banner) settings.
show page-customization Lists whether the UAG is set to use custom login and access pages or the
default ones.
Table 171 Command Summary: Customization (continued)
COMMAND DESCRIPTION
Table 172 Command Summary: Host Name
COMMAND DESCRIPTION
[no] domainname domain_name Sets the domain name. The no command removes the domain name.
domain_name: This name can be up to 254 alphanumeric characters long. Spaces are not
allowed, but dashes “-” and underscores “_” are accepted.
[no] hostname hostname Sets a descriptive name to identify your UAG. The
no command removes the host name.
show fqdn Displays the fully qualified domain name.
