Zyxel UAG5100 [94/361] Interface parameter command examples
![Zyxel UAG5100 [94/361] Interface parameter command examples](/views2/1169100/page94/bg5e.png)
Chapter 13 Interfaces
UAG CLI Reference Guide
94
13.2.3 Interface Parameter Command Examples
This table shows an example of each interface type’s sub-commands. The sub-commands vary for
different interface types.
13.2.4 RIP Commands
This table lists the commands for RIP settings.
Table 40 Examples for Different Interface Parameters
ETHERNET VIRTUAL INTERFACE PPPOE/PPTP
Router(config)# interface wan1
Router(config-if-wan1)#
description
downstream
exit
ip
mac
mss
mtu
no
ping-check
shutdown
traffic-prioritize
type
upstream
use-defined-mac
Router(config)# interface wan1:1
Router(config-if-vir)#
description
downstream
exit
ip
no
shutdown
upstream
Router(config)# interface wan1_ppp
Router(config-if-ppp)#
account
bind
connectivity
description
downstream
exit
local-address
metric
mss
mtu
no
ping-check
remote-address
shutdown
traffic-prioritize
upstream
VLAN BRIDGE
Router(config)# interface vlan1
Router(config-if-vlan)#
description
downstream
exit
ip
mss
mtu
no
ping-check
port
shutdown
traffic-prioritize
type
upstream
vlan-id
Router(config)# interface br0
Router(config-if-brg)#
description
downstream
exit
ip
join
mss
mtu
no
ping-check
shutdown
traffic-prioritize
type
upstream
Table 41 interface Commands: RIP Settings
COMMAND DESCRIPTION
router rip Enters sub-command mode.
[no] network interface_name Enables RIP for the specified interface. The no command disables RIP
for the specified interface.
[no] passive-interface interface_name Sets the RIP direction of the specified interface to in-only. The
no
command makes RIP bi-directional in the specified interface.
[no] outonly-interface interface_name Sets the RIP direction of the specified interface to out-only. The
no
command makes RIP bi-directional in the specified interface.
interface interface_name Enters sub-command mode.
