![Zyxel UAG5100 [138/361] Command description](/views2/1169100/page138/bg8a.png)
Chapter 21 VPN 1-1 Mapping
UAG CLI Reference Guide
138
21.2.1 vpn-1-1-map pool Sub-commands
The following table describes the sub-commands for the vpn-1-1-map pool command.
21.2.2 vpn-1-1-map pool Command Examples
The following commands create a pool profile and display the settings.
21.2.3 vpn-1-1-map rule Sub-commands
The following table describes the sub-commands for several vpn-1-1-map rule commands. Note
that not all rule commands use all the sub-commands listed here.
Table 79 vpn-1-1-map pool Sub-commands
COMMAND DESCRIPTION
address address_object Configures the name of the IP address object the profile is set to use.
An address object presents the IP address(es), which can be assigned
to the matched users by the UAG.
Note: You cannot configure an address group object at the time of
writing.
Note: It's recommended that the IP addresses of the configured
address object and the WAN interface are in the same subnet
so that the UAG can receive response packets from the remote
node.
exit Leaves the sub-command mode.
interface interface_name Sets the interface through which the UAG sends traffic from the
matched users.
Router# configure terminal
Router(config)# vpn-1-1-map pool pool1
Router(vpn-1-1-map-pool-pool1)# address WAN-1
Router(vpn-1-1-map-pool-pool1)# interface wan1
Router(vpn-1-1-map-pool-pool1)# exit
Router(config)# show vpn-1-1-map pool
Pool: pool1
address: WAN-1
interface: wan1
Router(config)#
Table 80 vpn-1-1-map rule Sub-commands
COMMAND DESCRIPTION
activate Enables the VPN 1-1 mapping rule.
deactivate Disables the VPN 1-1 mapping rule.
exit Leaves the sub-command mode.
flush pool Removes all pool profile(s) and resets the pool profile setting to the
default (any). any means all IP address.
