Chapter 18 Zones
UAG CLI Reference Guide
127
18.2.1 Zone Command Examples
The following commands add interfaces vlan123 and vlan234 to zone A and block intra-zone traffic.
Router# configure terminal
Router(config)# zone A
Router(zone)# interface vlan123
Router(zone)# interface vlan234
Router(zone)# block
Router(zone)# exit
Router(config)# show zone
No. Name Block Member
===========================================================================
1 LAN1 no lan1
2 LAN2 no lan2
3 WAN yes wan1,wan2,wan1_ppp,wan2_ppp
4 DMZ yes dmz
5 SSL_VPN no
6 IPSec_VPN no
7 A yes vlan123,vlan234
Router(config)# show zone A
blocking intra-zone traffic: yes
No. Type Member
===========================================================================
1 interface vlan123
2 interface vlan234
