UAG CLI Reference Guide 177
CHAPTER 34
Billing
34.1 Billing Overview
You can use the built-in billing function to setup billing profiles. A billing profile describes how to
charge users. This chapter also shows you how to select an accounting method or configure a
discount price plan.
34.2 Billing Commands
This table lists the billing commands. You must use the configure terminal command to
enter the configuration mode before you can use these commands.
Table 109 billing Commands
COMMAND DESCRIPTION
billing accounting-method
{accumulation | time-to-finish }
Sets how the UAG accounts the time.
accumulation: to allow each user a one-time login. Once the user logs in,
the system starts counting down the pre-defined usage even if the user
stops the Internet access before the time period is finished. If a user
disconnects and reconnects before the allocated time expires, the user does
not have to enter the user name and password to access the Internet again
time-to-finish: to allow each user multiple re-login until the time
allocated is used up. The UAG accounts the time that the user is logged in
for Internet access
billing accumulation idle-detection
timeout <1..60>
Specifies the idle timeout between 1 and 60 minutes. The UAG
automatically disconnects a computer from the network after a period of
inactivity. The user may need to enter the username and password again
before access to the network is allowed.
billing accumulation-expire {day
<1..360> | hour <1..24>}
Specifies a time unit and number to set how long to wait before the UAG
deletes an idle account.
billing currency {eur | gbp | usd |
user-define currency_code }
Sets the appropriate currency unit.
currency_code: enter a three-letter alphabetic code, such as TWD or JPY.
billing decimal-places <2> Sets the number of decimal places to be used for billing.
billing decimal-symbol {comma | dot} Sets the UAG to use a dot (.) or a comma (,) for the decimal point.
[no] billing discount activate Activates the discount price plan.
The no command disables the discount price plan.
billing discount button {a | b | c}
[charge-by-level]
Specifies a button to assign the base charge.
charge-by-level: to charge the rate at each successive level from the
first level (most expensive per unit) to the highest level (least expensive
per unit) that the total purchase reaches.
