Chapter 3 Object Reference
UAG CLI Reference Guide
44
3.1.1 Object Reference Command Example
This example shows how to check which configuration is using an address object named
LAN1_SUBNET. For the command output, firewall rule 3 named LAN1-to-UAG is using the address
object.
show reference object-group username
[username]
Displays which configuration settings reference the specified user group
object.
show reference object-group address
[object_name]
Displays which configuration settings reference the specified address
group object.
show reference object-group service
[object_name]
Displays which configuration settings reference the specified service
group object.
show reference object-group interface
[object_name]
Displays which configuration settings reference the specified trunk object.
show reference object-group aaa ad
[group_name]
Displays which configuration settings reference the specified AAA AD
group object.
show reference object-group aaa ldap
[group_name]
Displays which configuration settings reference the specified AAA LDAP
group object.
show reference object-group aaa radius
[group_name]
Displays which configuration settings reference the specified AAA RADIUS
group object.
Table 6 show reference Commands (continued)
COMMAND DESCRIPTION
Router(config)# show reference object address LAN1_SUBNET
LAN1_SUBNET References:
Category
Rule Priority Rule Name
Description
===========================================================================
Firewall
3 N/A
LAN1-to-UAG
Router(config)#
