Chapter 5 Registration
UAG CLI Reference Guide
51
5.4.1 Command Examples
The following command displays the service registration status and type and how many days
remain before the service expires.
5.5 Country Code
The following table displays the number for each country.
Router# configure terminal
Router(config)# show service-register status all
Service Status Type Count Expiration
===============================================================================
Extension User Licensed standard 299 n/a
External-AP-Control Licensed standard 9 n/a
Table 11 Country Codes
COUNTRY
CODE
COUNTRY NAME
COUNTRY
CODE
COUNTRY NAME
001 Afghanistan 002 Albania
003 Algeria 004 American Samoa
005 Andorra 006 Angola
007 Anguilla 008 Antarctica
009 Antigua & Barbuda 010 Argentina
011 Armenia 012 Aruba
013 Ascension Island 014 Australia
015 Austria 016 Azerbaijan
017 Bahamas 018 Bahrain
019 Bangladesh 020 Barbados
021 Belarus 022 Belgium
023 Belize 024 Benin
025 Bermuda 026 Bhutan
027 Bolivia 028 Bosnia and Herzegovina
029 Botswana 030 Bouvet Island
031 Brazil 032 British Indian Ocean Territory
033 Brunei Darussalam 034 Bulgaria
035 Burkina Faso 036 Burundi
037 Cambodia 038 Cameroon
039 Canada 040 Cape Verde
041 Cayman Islands 042 Central African Republic
043 Chad 044 Chile
045 China 046 Christmas Island
047 Cocos (Keeling) Islands 048 Colombia
049 Comoros 050 Congo, Democratic Republic of the
