UAG CLI Reference Guide 304
CHAPTER 59
Logs
This chapter provides information about the UAG’s logs.
Note: When the system log reaches the maximum number of log messages, new log
messages automatically overwrite existing log messages, starting with the oldest
existing log message first.
See the User’s Guide for the maximum number of system log messages in the UAG.
59.1 Log Commands Summary
The following table describes the values required for many log commands. Other values are
discussed with the corresponding commands.
The following sections list the logging commands.
59.1.1 Log Entries Commands
This table lists the commands to look at log entries.
Table 191 Input Values for Log Commands
LABEL DESCRIPTION
interface_name The name of the interface. This depends on the UAG model.
See Table 37 on page 86 for detailed information about the interface name.
module_name The name of the category; kernel, syslog, .... The default category includes debugging
messages generated by open source software. The
all category includes all messages in
all categories.
protocol The name of a protocol such as TCP, UDP, ICMP.
Table 192 logging Commands: Log Entries
COMMAND DESCRIPTION
show logging entries [priority pri] [category
module_name] [srcip ip] [dstip ip] [service
service_name] [begin <1..512> end <1..512>]
[keyword keyword] [srciface interface_name]
[dstiface interface_name] [protocol protocol]
Displays the specified entries in the system log.
pri: alert | crit | debug | emerg | error | info | notice | warn
keyword: You can use alphanumeric and
()+/:=?!*#@$_%-
characters, and it can be up to 63 characters long. This searches
the message, source, destination, and notes fields.
show logging entries field field [begin
<1..512> end <1..512>]
Displays the specified fields in the system log.
field: time | msg | src | dst | note | pri | cat | all
