Chapter 52 ISP Accounts
UAG CLI Reference Guide
259
[no] service-name {ip | hostname
| service_name}
Sets the service name for the specified PPPoE ISP account. The no
command clears the service name.
hostname: You may up to 63 alphanumeric characters, dashes (-), or
periods (.), but the first character cannot be a period.
service_name: You can use up to 63 alphanumeric characters, underscores
(_), dashes (-), and
@$./ characters.
[no] server ip Sets the PPTP server for the specified PPTP ISP account. The no command
clears the server name.
[no] encryption {nomppe | mppe-40
| mppe-128}
Sets the encryption for the specified PPTP ISP account. The
no command
sets the encryption to nomppe.
[no] connection-id connection_id Sets the connection ID for the specified PPTP ISP account. The
no command
clears the connection ID.
connection_id: You can use up to 31 alphanumeric characters, underscores
(_), dashes (-), and colons (:).
Table 165 PPPoE and PPTP ISP Account Commands (continued)
COMMAND DESCRIPTION
