UAG CLI Reference Guide 210
CHAPTER 42
Application Patrol
This chapter describes how to set up application patrol for the UAG.
42.1 Application Patrol Overview
Application patrol provides a convenient way to manage the use of various applications on the
network. It manages general protocols (for example, http and ftp) and instant messenger (IM),
peer-to-peer (P2P), Voice over IP (VoIP), and streaming (RSTP) applications. You can even control
the use of a particular application’s individual features (like text messaging, voice, video
conferencing, and file transfers). Application patrol also has powerful bandwidth management
including traffic prioritization to enhance the performance of delay-sensitive applications like voice
and video.
Note: The UAG checks firewall rules before application patrol rules for traffic going
through the UAG. To use a service, make sure both the firewall and application
patrol allow the service’s packets to go through the UAG.
Application patrol examines every TCP and UDP connection passing through the UAG and identifies
what application is using the connection. Then, you can specify, by application, whether or not the
UAG continues to route the connection.
42.2 Application Patrol Commands Summary
The following table describes the values required for many application patrol commands. Other
values are discussed with the corresponding commands.
The following sections list the application patrol commands.
Table 129 Input Values for Application Patrol Commands
LABEL DESCRIPTION
profile_name Type the name of the profile. You may use 1-31 alphanumeric characters, underscores(_),
or dashes (-), but the first character cannot be a number. This value is case-sensitive.
description This is a description of the App Patrol Profile.
