UAG CLI Reference Guide 291
CHAPTER 58
File Manager
This chapter covers how to work with the UAG’s firmware, certificates, configuration files, packet
trace results, shell scripts and temporary files.
58.1 File Directories
The UAG stores files in the following directories.
58.2 Configuration Files and Shell Scripts Overview
You can store multiple configuration files and shell script files on the UAG.
When you apply a configuration file, the UAG uses the factory default settings for any features that
the configuration file does not include. Shell scripts are files of commands that you can store on the
UAG and run when you need them. When you run a shell script, the UAG only applies the
commands that it contains. Other settings do not change.
You can edit configuration files or shell scripts in a text editor and upload them to the UAG.
Configuration files use a .conf extension and shell scripts use a .zysh extension.
Table 187 FTP File Transfer Notes
DIRECTORY FILE TYPE
FILE NAME
EXTENSION
A
A. After you log in through FTP, you do not need to change directories in order to upload the firmware.
Firmware (upload only) bin
cert Non-PKCS#12 certificates cer
conf Configuration files conf
packet_trace Packet trace results (download only)
script Shell scripts .zysh
tmp Temporary system maintenance files and crash dumps for technical
support use (download only)
