14
<dc@QvW=>@d@<:c@<Q]>[\]@=<Qe
FR
EN DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
SPECIFICATIONS
#>=Y[\]_a\@o@\:]@=<Q
=Yac z{z
Motor 18 V
No Load Speed 1200 min
-1
Shrubber blade
cutting length
200 mm
Grass shear blade
width
100 mm
Sound pressure
level
L
PA
=68 dB(A), K
PA
=3 dB(A)
Measured sound
power level
L
WA
=88 dB(A), K
WA
=3 dB(A)
Vibration ah= 2.3 m/s
2
,K=1.5 m/s
2
$a@dv]@]vk:]]a>h_:\
With grass shear
blade
1.75 Kg
With shrubber
blade
2.1 Kg
Battery Pack
(not included):
BPL-1815 / BPP-1817M /
BPP-1815M / BPP-1817MG /
ABP1801 / ABP1802 /
BPL-1820 / BPL-1820G
Charger
(not included):
BC-1800 / BC-1800M /
BC-1815S / BC-1815SMG /
BCL1418 / ACR1800 /
BCL-1800 / BCL-1800G
FEATURES
Fig. 1
1. REAR HANDLE
2. TRIGGER LOCK BUTTON
3. TRIGGER
4. SHRUBBER BLADE
5. SHRUBBER BLADE SHEATH
6. GRASS SHEAR BLADE SHEATH
7. GRASS SHEAR BLADE
Fig. 2
8. BATTERY PACK
9. COVER
Fig. 3
2. TRIGGER LOCK BUTTON
3. TRIGGER
Fig. 5
4. SHRUBBER BLADE
7. GRASS SHEAR BLADE
10. BLADE SECURING KNOB
11. BLADE POST
OPERATION
#'W'%%e
Q Place the battery pack in the grass shear / shrubber.
Align raised rib on battery pack with groove in grass
shear / shrubber. See Figure 2.
Q Make sure the latches on the battery pack snap in place
and that battery pack is secured in grass shear / shrubber
before beginning operation.
#'W'%%e
Q Locate latches of battery pack and depress to release
the battery pack from the grass shear / shrubber. See
Figure 2.
Q Remove battery pack from the grass shear / shrubber.
CAUTION
When placing battery pack in your grass shear /
shrubber, be sure raised rib on battery pack aligns with
groove in grass shear / shrubber and latches snap in
place properly. Improper assembly of battery pack can
cause damage to internal components.
STARTING THE GRASS SHEAR / SHRUBBER
Q Remove the blade cover.
Q Press and hold the trigger lock button. See Fig. 3 .
Q Release the trigger lock button and continue to squeeze
the trigger for extended operation.
STOPPING THE GRASS SHEAR / SHRUBBER
Q Release the trigger to stop the grass shear / shrubber.
Q Upon release of the trigger, the trigger lock button will
be automatically reset to the lock position.
%We
aa@d[>a}
Q Remove battery pack from unit and place unit upside
down on a workbench.
Q Remove the knob by turning counterclockwise.
Q Remove the blade.
