C-13
Appendix C: SAS-846EL Backplane Specications
C-13 Chassis Power Card and Support Cables
Power Card
Part Number Part Type Where Used
CSE-PTJBOC-CB1 Power card
Allows the chassis to be in a
JBOD (Just a Bunch of Drives)
system.
Chassis Power Card
In a cascaded conguration, the rst chassis includes a motherboard and at least
one Host Bus Adapter (HBA). Other servers in this enclosed system, include a
power card. This section describes the supported power card for the SAS-846
series backplane.
For more information, see the PCC-JBPWR2 power card manual. This manual can
be found at the http://www.supermicro.com or as an appendix in the SAS-846EL
chassis manual.
AA
AA
AA
REV 1.00
JBPWR2
Figure C-10: Chassis Power Card (Sold Separately)
