E-13
Appendix E: BPN-SAS3-846EL Backplane Specications
Supported Internal HBA Cables
Use the following cables to create connections between the internal HBA and
BPN-SAS3-846EL model backplane. The cables required depend upon the HBA
connector.
IMPORTANT: See Section 3-3 of this manual, Failover with RAID Cards and
Multiple HBAs for important information on supported congurations.
Cable Name: Internal iPass (Mini-SAS) to HD (Mini-SAS)
Part #: CBL-SAST-0508-01 Length: 50 cm (19 inches)
Part #: CBL-SAST-0507-01 Length: 80 cm (31 inches)
Description: This cable has an iPass (SFF-8087/Mini-SAS) connector (36-pin) at one
end and a Mini-SAS HD (SFF-8643) connector at the other end. It connects from the
SAS2 HBA to the BPN-SAS3-846EL model backplane.
Cable name: Internal HD (Mini-SAS) to HD (Mini-SAS)
Part #: CBL-SAST-0568 Length: 35 cm (13 inches)
Part #: CBL-SAST-0593 Length: 60 cm (23 inches)
Part #: CBL-SAST-0531 Length: 80 cm (31 inches)
Description: This cable has a Mini-SAS HD (SFF-8643) connector at both ends. It
connects from the SAS3 HBA to the BPN-SAS3-846EL model backplane.
