SC846 Chassis Models
Model HDD PCI Slots Power Supply
SC846BE1C-R1K28B
24x SAS3/SATA
Up to 3 rear/internal
7x FF
1280 W Redundant
Platinum level
SC846BE2C-R1K28B
24x SAS3/SATA
Up to 3 rear/internall
7x FF
1280 W Redundant
Platinum level
SC846BE16-R1K28B
24x SAS2/SATA
Up to 3 rear/internal
7x FF
1280 W Redundant
Platinum level
SC846BE26-R1K28B
24x SAS2/SATA
Up to 3 rear/internal
7x FF
1280 W Redundant
Platinum level
SC846BE16-R920B
24x SAS2/SATA
Up to 3 rear/internal
7x FF
920 W Redundant
Platinum level
SC846BE26-R920B
24x SAS2/SATA
Up to 3 rear/internal
7x FF
920 W Redundant
Platinum level
SC846BA-R1K28B
24x SAS/SATA
Up to 3 rear/internal
7x FF
1280 W Redundant
Platinum level
SC846BA-R920B
24x SAS/SATA
Up to 3 rear/internal
7x FF
920 W Redundant
Platinum level
SC846E16-R1200B
24x SAS2/SATA
Up to 3 internal
7x FF
1200 W Redundant
Gold level
SC846E26-R1200B
24x SAS2/SATA
Up to 3 internal
7x FF
1200 W Redundant
Gold level
Chapter 1
Introduction
1-1 Overview
Optimized for enterprise-level high-capacity storage applications, Supermicro's
SC846 chassis features 24 hot-swap 3.5" SAS/SATA hard drive trays and 2 xed
internal hard drive bays in a 4U form factor. The design offers maximum HDD per
space ratio, high power efciency, optimized HDD signal trace routing and improved
HDD tray design to dampen HDD vibrations and maximize performance. Equipped
high-efciency redundant power supplies and ve hot-swap redundant cooling fans
the SC846 is a reliable and trouble-free storage system.
Chapter 1: Introduction
1-1
