B-8
SC846 Chassis Manual
Fan Jumper Settings
This backplane can use up to four fans. To utilize each fan, you must congure
both jumpers as instructed below.
Fan Jumper Settings
Jumper Jumper Settings Note
JP61
1-2: With fan (default)
2-3: No fan
FAN#1
JP97
1-2: With fan (default)
2-3: No fan
FAN#1
JP62
1-2: With fan (default)
2-3: No fan
FAN#2
JP98
1-2: With fan (default)
2-3: No fan
FAN#2
JP63
1-2: With fan (default)
2-3: No fan
FAN#3
JP99
1-2: With fan (default)
2-3: No fan
FAN#3
JP64
1-2: With fan (default)
2-3: No fan
FAN#4
JP100
1-2: With fan (default)
2-3:No fan
FAN#4
Jumper Settings
Jumper Jumper Settings Note
JP35
1-2: Reset
2-3: Default
MG 9072 chip reset #1
JP50
1-2: Reset
2-3: Default
MG 9072 chip reset #2
JP129
1-2: Reset
2-3: Default
MG 9072 chip reset #3
