D-20
SC846 Chassis User's Manual
Description: Internal cascading cable. Connects the backplane to the HBA or
external port. Used in dual port environments.
Cable Name: SAS Dual-port Cable Assembly, 68/76 cm
Part #: CBL-0168L
Ports: Dual
Placement: Internal cable
Dual HBA Conguration Cables
Dual Port Cable
Assembly
Figure D-15: Dual Port Internal Cable (CBL-0168L)
