Chapter 3: System Interface
3-5
3-5 Power Supply LEDs
On the rear of the power supply module, an LED displays the status.
• Solid Green: When illuminated, indicates that the power supply is on.
• Solid Amber: When illuminated, indicates the power supply is plugged in and
turned off, or the system is off but in an abnormal state.
• Blinking Amber: When blinking, this system power supply temperature has
reached 63C. The system will automatically power-down when the power supply
temperature reaches 70C and restart when the power supply temperature goes
below 60C.
