![Supermicro CSE-846TQ-R900B [118/160] Dual sas hba and cascaded configuration](/img/pdf.png)
Supermicro CSE-846TQ-R900B [118/160] Dual sas hba and cascaded configuration
![Supermicro SC846E16-R1200B [118/160] Dual sas hba and cascaded configuration](/views2/1190280/page118/bg76.png)
C-24
SC846 Chassis Manual
Cable 0166L
(External cables)
PRI_J0
PRI_J1
PRI_J2
SEC_J0 SEC_J1
SEC_J2
J17
WWN
Port A Expander 1
HBA
Port B Expander 2
Power Card
PRI_J0
PRI_J1
PRI_J2
SEC_J0 SEC_J1
SEC_J2
J17
WWN
Port A Expander 1
Power Card
PRI_J0
PRI_J1
PRI_J2
SEC_J0 SEC_J1
SEC_J2
J17
WWN
Port A Expander 1
Cable 0168L
(internal cable)
Dual Port Cable
Assembly
Figure C-24: Dual SAS HBA with Cascaded Conguration
Dual SAS HBA and Cascaded Conguration
HBA
Port B Expander 2
Port B Expander 2
IMPORTANT: See Section C-12 of this manual, Failover with RAID Cards and
Multiple HBAs for important information on supported congurations.
