SC846X Chassis Manual
Front SAS/SATA Connectors and LED Indicators
Drive Number Label
HDD Activity LED
(blue)
Failure LED
(red)
SAS #20 J20 ACT20 FAIL20
SAS #21 J21 ACT21 FAIL21
SAS #22 J22 ACT22 FAIL22
SAS #23 J23 ACT23 FAIL23
