D-14
SC846 Chassis User's Manual
Description: This cable has an iPass (SFF-8087/Mini-SAS) connector (36-pin) at
each end. It connects from the HBA to the SAS2-846EL backplane.
Cable Name: iPass (Mini-SAS) to iPass (Mini-SAS)
Part #: CBL-0108L-02 Length: 39 cm (15 inches)
Part #: CBL-0109L-02 Length: 22 cm (9 inches)
Part #: CBL-0110L-02 Length: 18 cm (7 inches)
Supported External HBA to Backplane Cable
Use the following cable if your external HBA has an InniBand connector.
Description: This cable has an InniBand connector (SFF-8470) on one end and
an SFF-8088-1X (26-pin) at the other end.
Cable Name: SAS InniBand to Mini SAS X4 1M cable, PBF
Part #: CBL-0200L Length: 1 meter
Figure D-8: The CBL-0200L Cable
