D-9
Appendix D: SAS2-846EL Backplane Specications
Front LED Indicators
Front Connector Hard Drive Activity LED Failure LED
SAS #0 ACT #0 FAIL #0
SAS #1 ACT #1 FAIL #1
SAS #2 ACT #2 FAIL #2
SAS #3 ACT #3 FAIL #3
SAS #4 ACT #4 FAIL #4
SAS #5 ACT #5 FAIL #5
SAS #6 ACT #6 FAIL #6
SAS #7 ACT #7 FAIL #7
SAS #8 ACT #8 FAIL #8
SAS #9 ACT #9 FAIL #9
SAS #10 ACT #10 FAIL #10
SAS #11 ACT #11 FAIL #11
SAS #12 ACT #12 FAIL #12
SAS #13 ACT #13 FAIL #13
SAS #14 ACT #14 FAIL #14
SAS #15 ACT #15 FAIL #15
SAS #16 ACT #16 FAIL #16
SAS #17 ACT #17 FAIL #17
SAS #18 ACT #18 FAIL #18
SAS #19 ACT #19 FAIL #19
SAS #20 ACT #20 FAIL #20
SAS #21 ACT #21 FAIL #21
SAS #22 ACT #22 FAIL #22
SAS #23 ACT #23 FAIL #23
